Bluffdale Heating & Air Conditioning Work Gallery

Every job in the field gets documented. Not for marketing. For the file. Combustion analyzer readings before and after the repair. Static pressure across the air handler before we touch the duct system, then after. Refrigerant weigh-out on recovery, weigh-in on the new charge. Thermal imager scans of return trunks, evaporator faces, and heat exchanger surfaces where a hairline crack would show as a bright ribbon against a cool background. This gallery is a selection of what those files look like — grouped by service category, geographically anchored to the neighborhoods in Bluffdale, Riverton, Draper, Herriman, Lehi, and South Jordan where the work happened.

New Installations

R-454B Condenser Installs at Point of the Mountain Elevation

The 2025 refrigerant transition means every new AC install and heat pump condenser we set now uses R-454B (mildly flammable A2L classification) instead of legacy R-410A. That changes line-set brazing procedure, evacuation depth (target: 500 microns held for 15 minutes), and leak-check protocol. Photos in this section document the install sequence on Carrier, Trane, Lennox, and Rheem R-454B condensers in Independence at the Point, Spring View Farms, and the Porter Rockwell Boulevard corridor — equipment nameplate, line-set diameter (⅜” liquid, ⅞” suction on 3-ton, upsized for elevation), charge weigh-in on a digital scale, and the completed nitrogen pressure test at 300 PSI.

Cold-Climate Heat Pump Commissioning

Mitsubishi Hyper-Heat, Daikin Aurora, and Bosch IDS Premium installs at Bluffdale’s 4,436-foot elevation. Sizing based on the ASHRAE 99% winter design temperature of 9°F for Salt Lake Valley floor, not the manufacturer’s optimistic AHRI 95°F rating. Photos document the outdoor unit set on a mini-split pad (elevated for snow clearance and drain-line ice protection), the indoor cassette or hydronic module tie-in, and the commissioning readout showing 100% capacity delivered at 5°F outdoor.

High-Altitude Furnace Installs

Carrier, Trane, Lennox, Rheem, and Bryant 90%+ AFUE modulating furnaces installed with elevation derate applied per manufacturer installation manual. Standard sea-level combustion assumes 0.0765 lb/ft³ air density. At Bluffdale’s 4,436 feet: roughly 0.0649 lb/ft³. Photos document the venting configuration (UMC 510-compliant PVC or polypropylene terminations), gas pressure verification at the manifold on Dominion Energy delivery (7″ WC nominal), and the combustion analyzer readout showing under-100 ppm CO air-free.

Boiler and Hydronic System Installs

Cast iron sectional, cast iron monobloc, and modulating-condensing wall-hung boiler installs. Common on older Redwood Road ranch homes and pre-1980 farmhouses along Pony Express Road where original hydronic systems occasionally pre-date 1960. Photos show the boiler bench-set on a poured pad, near-boiler piping copper and PEX runs, the outdoor reset control wiring, and the commissioning printout confirming combustion efficiency above 95% AFUE.

Before & After

Ductwork Rebuilds

A 2022 Spring View Farms retrofit is representative. Original builder installed a 4-ton condenser paired with a return trunk sized for 2.5 tons — static pressure was running 0.9″ WC across the air handler, well over the 0.5″ WC residential spec. The before photo shows the crushed return duct at the plenum tie-in. The after photo shows the rebuilt sheet-metal return trunk sized for the actual delivered CFM, with static pressure dropped to 0.42″ WC. Utility bill dropped 22% the following cooling season.

Heat Exchanger Diagnostics

Borescope photos of secondary heat exchangers where a competitor had flagged a “cracked” heat exchanger without documentation. Our borescope image showed carbon staining from a partially-clogged inducer drain, not a crack. Cleaned the drain, verified combustion analyzer readings, and the customer kept a 9-year-old Trane XV80 running another six winters. The before photo shows the actual staining pattern. The after photo shows the same surface with the CO reading (18 ppm air-free) documenting a clean burn.

Line-Set Repairs on High-Elevation Sun-Loaded Installs

South-facing condensers in Independence at the Point and Draper Suncrest run 8–12°F hotter than the airport NWS station because of solar loading on adjacent wall surfaces. Photos document line-set insulation upgrades, condensate line rerouting, and the addition of factory-approved refrigerant charge subcoolers where necessary to maintain manufacturer AHRI capacity ratings at elevated ambient.

Emergency Repair Callouts

No-Heat Calls During PCAPS Inversion Season

Photos of dispatched service vans staged on Bluffdale driveways at 2 a.m. and 3 a.m. during November through February. Inversion-season no-heat calls run heavier volume — the ambient temperature swings, the equipment cycles harder, and marginal components (flame sensors, pressure switches, hot surface igniters, inducer motors) fail at the worst time. Photos capture the diagnostic sequence: static pressure reading before the repair, meter shots of the failed component, replacement part on the truck, and the combustion analyzer confirming safe operation post-repair.

AC Failures During July and August Heat Events

Photos of failed capacitors (measured at 8 microfarads on a 35 microfarad rated component — a classic no-start symptom), refrigerant leaks located with electronic detectors and UV dye, and iced-over evaporator coils where the actual failure was a partially-restricted return filter (photographed alongside the replacement MERV 13 pleated media).

Indoor Air Quality Projects

MERV 13 and HEPA Bypass Installs for PCAPS Season

Photos of filter cabinet retrofits, whole-home HEPA bypass systems installed on Carrier, Trane, and Lennox air handlers, and the manometer readings verifying that static pressure across the upgraded filter media stays within the 0.5″ WC residential blower spec. On homes where a household member has documented FEV1 below 80% of predicted or a diagnosed dust allergy, photos document the whole-home HEPA installation with dedicated bypass ducting.

HRV and ERV Commissioning

Heat recovery ventilator and energy recovery ventilator installs on post-2015 tight-envelope builds in Independence at the Point, Day Ranch, and Jordan Narrows. Photos capture the balance test (supply CFM equal to exhaust CFM within 10%), the fresh-air intake terminated per UMC clearance requirements, and the winter dampering verified for below-freezing operation.

Steam and Bypass Humidifier Installs

Photos document humidifier canister service intervals corrected for Jordan Aquifer water at 15–25 grains per gallon hardness. Standard 24-month rated humidifier pads last 8–14 months in Bluffdale water without hardness correction. Our install photos show the water softener or reverse osmosis feed tie-in that extends humidifier life to manufacturer spec.

Commercial Rooftop and Service

Carrier 48HC Rooftop Unit Installs

Retail and small office installations along Porter Rockwell Boulevard, dental and medical clinics on the Riverton border, and light-industrial buildings near Camp Williams. Photos show the crane-set rooftop unit on a factory curb, the economizer damper for outdoor air ventilation sized to ASHRAE 62.1 for the occupancy type, and the commissioning readout for supply air temperature and static pressure delivered.

Preventive Maintenance Service Contracts

Photos of quarterly rooftop unit inspections on active service contracts — belt tension check, condenser coil pressure-wash, filter change to MERV 13, and combustion analyzer confirmation on gas-heat sections. Written report and photo log deliver to the property manager after each visit.

Why We Document Every Job

Two reasons. First, when a homeowner asks why the quote is $180 for a pressure switch instead of $12,800 for a new furnace, the borescope photo of the intact heat exchanger and the meter shot of the failed pressure switch answer the question in a way words don’t. Second, when a warranty claim comes back six months later, the file has the install photos, the manufacturer serial numbers, the combustion analyzer printout, and the commissioning static pressure reading. Warranty claims that arrive with documentation get approved. Claims without documentation don’t.

Frequently Asked Questions

Why does an HVAC company keep a photo gallery of work?
Two reasons: transparency for homeowners considering a repair-versus-replace decision, and documentation for warranty claims. When we quote a $180 pressure switch replacement instead of a $12,800 furnace replacement, the borescope photo of the intact heat exchanger and the meter shot of the failed component justify the recommendation in a way words don’t. When a manufacturer warranty claim arrives six months after install, the commissioning photos, serial numbers, and combustion analyzer printout on file get the claim approved.
What do you photograph on every job?
Combustion analyzer readout (target: under 100 ppm CO air-free, stack temperature within manufacturer spec), static pressure across the air handler (residential target under 0.5″ WC), refrigerant weigh-out and weigh-in on the digital scale, thermal imager scans of return trunks and heat exchanger surfaces, meter readings on capacitors and motors compared to nameplate FLA, and gas manifold pressure verification on Dominion Energy delivery (7″ WC nominal). Every reading gets filed with the job.
Are the photos in this gallery from real Bluffdale customer jobs?
Yes. Every photo is from actual field work performed by Bluffdale Heating and Air Conditioning technicians in Bluffdale, Riverton, Draper, Herriman, Lehi, South Jordan, and extended-service areas across the Salt Lake Valley. Customer identifying information (address, homeowner name, meter numbers) is redacted or cropped before publication. Named case studies elsewhere on the site (Marcus D. in Independence at the Point, Rebecca K. on Porter Rockwell Boulevard, Lin K. on Pony Express Road) reference customers who signed a release for their story to appear.
Can I request specific job photos before hiring the company?
Yes. If you’re considering a specific service — R-454B condenser install, Mitsubishi Hyper-Heat commissioning, cast iron boiler replacement, MERV 13 filter cabinet upgrade — call the office at (801) 610-6528 or email info@bluffdaleairconditioningheating.site and we’ll send anonymized photos and commissioning data from comparable jobs in your neighborhood or a comparable Bluffdale construction era.
Do you share before-and-after measurements alongside the photos?
Yes. Every before-and-after series in the gallery includes the technical delta: static pressure before/after (typically 0.9″ WC down to 0.4″ WC on duct rebuilds), utility bill percentage change over the following cooling or heating season (documented drops of 18–25% are typical on properly-sized retrofits), CO reading pre- and post-repair, or refrigerant charge verification against manufacturer spec. Marketing photos without measurements are just decoration.
